10.5 To Remove the Measurement Results
After completing the measurement, you can remove the specified measurement item
or remove all the measurement items.
Remove the Specified Measurement Item
• In the Setting menu of the specified measurement item, click or tap Remove to
remove the current measurement item.
• Click or tap any measurement item shown in the result list. Then the sub-menu is
displayed. Click or tap
Remove to remove the currently selected measurement
item.
• To remove the result list displayed at the right section of the screen, drag the
result list of the specified measurement item to the right. To remove the result
list displayed at the bottom of the screen, drag it downward to remove it.
Remove All Measurement Items
• In the Setting menu, click or tap Remove All to remove all the measurement
items.
• Click or tap any measurement item shown in the result list. Then the sub-menu.
Click or tap
Remove All to remove all the displayed measurement items.
10.6 Auto Measurement
When the oscilloscope is properly connected and received a valid signal, click or tap
the function navigation icon at the lower-left corner of the screen to select the
Auto icon to enable the waveform auto setting function and open the auto setting
function menu. You can also press on the front panel to enable the waveform
auto setting and open the auto setting interface.
• Click or tap the first icon, and then signal in two periods is displayed
automatically on the screen. Meanwhile, the system will make measurements for
the "period" and "frequency" of the currently displayed waveforms. The
measurement results are displayed at the right side of the screen under the
"Result" list.
• Click or tap the second icon, and then multiple periods of the signal are
displayed automatically on the screen. Meanwhile, the system will make
measurements for the "period" and "frequency" of the currently displayed
Measurements
Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO2000 User Guide
157
