Set the Trigger Logic for Zone Trigger
• A or B: triggers when one of the trigger conditions set for Zone A and Zone B is
met.
• A & B: triggers when both of the trigger conditions set for Zone A and Zone B
are met.
8.9 Trigger Output Connector
The trigger output connector ([AUX OUT]) on the rear panel of this series
oscilloscope can output trigger signals (trigger hardware) based on the current
setting.
Click or tap the function navigation icon > Utility. Click or tap Setup, and then in
the
AUX Out menu, select "TrigOut". A signal which reflects the current oscilloscope
capture rate can be output from [AUX OUT] connector each time a trigger is
generated by the oscilloscope. If this signal is connected to a waveform display device
to measure the frequency, the measurement result is the same as the current capture
rate.
If "PassFail" is selected for the
AUX Out menu, the instrument can output a pulse
from the [AUX OUT] connector when a pass/failed event is detected during the pass/
fail test.
To Trigger the Oscilloscope
MHO2000 User Guide
128
Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
