Click or tap the input field of Sample Position to set the sample position with the
pop-up numeric keypad. You can also use the specified knob indicated in the input
field to set it. Its settable range is from 10% to 90%.
Set the CAN-FD Baud
CAN-FD baud rate is a dedicated setting for the CAN-FD trigger. It is available only
when the MHO2000-AUTOA option has been installed. Click or tap the drop-down
button of CAN-FD Baud to select the variable baud rate from the drop-down list. The
available baud rates include 1 Mbps, 2 Mbps, 3 Mbps, 4 Mbps, and etc. You can also
self-define the baud rate.
Trigger Condition
Click or tap the drop-down button of When to select the desired trigger condition.
• SOF: triggers at the start of a frame.
• EOF: triggers at the end of a frame.
• Remote ID: triggers on the specified ID of Remote frame. When you select
Remote ID, you need to set the following parameters.
- Click or tap the ON/OFF tab for
Extended ID to enable or disable the
extended ID.
- Click or tap the input field of ID, and then the "Format" interface is
displayed. You can set the ID that needs to be operated on. For details, refer
to descriptions in
I2C Trigger
.
• Overload: triggers on the overload frames.
• Frame ID: triggers on the data frames with the specified ID. After selecting
Frame ID, you can refer to the "Remote ID" mentioned above to set Extended
ID and ID.
• Frame Data: triggers on the data frames with the specified Data. When you
select
Frame Data, you need to set the following parameters.
- Click or tap the input field of Data, and then the "Format" interface is
displayed. You can set the data bit that needs to be operated on. For
details, refer to descriptions in
I2C Trigger
.
- Click or tap the input field of Bytes to set the length of data with the pop-
up numeric keypad. You can also use the specified knob to set it. Its range
is from 1 to 8.
• Data & ID: triggers on the data frames with the specified ID and data. When you
select
Data & ID, you need to set ID, Extended ID, Data, and Bytes.
• Frame Error: triggers on the error frame.
• Bit Fill: triggers on the error frame with the bit fill.
To Trigger the Oscilloscope
