RIGOL
M300 Quick Guide
6
8 Menu Softkeys
Correspond to the menus above them. Pressing any softkey can enable the
corresponding menu.
9 View Switch
View the scan history information, channel status table,
measurement curve and channel information.
Scan history information: view the start time, scan sweep,
count, channel number as well as the corresponding
function, maximum, minimum, average and standard
deviation measured as well as the scan readings of each
channel of the latest scan.
Channel status table: display the current status of each
channel.
Measurement curve: display the measurement curve of the
specified channel.
Channel information: view the cycle count of each relay of
the module, the alarm messages of the current scan (the
first 100 on each alarm channel, including the reading and
time when the alarm is generated) and error messages (up
to 20).
Note: Up to 100 alarm messages on each alarm channel can be logged in the
alarm queue and the subsequent alarm messages would be lost. Up to 20 error
messages can be logged in the error queue and the other error messages will
also be lost.
10 Module Indicators
Correspond to the 5 module slots on the rear panel respectively. The
corresponding module indicator goes on when the module is inserted into the
slot on the rear panel.
