SM82S
STEREO LINE MIXER
Data Sheet-2
Parameter Specication Limit Units Conditions/Comments
Input Impedance: Ch's 1-8 100k 20%
..........Receive 100k 20%
..........Expand 20k 1%
Input Level: Nominal +4 1 dBu
..........Minimum -10 1 dBV
..........Maximum +26 1 dBu
Input Design Unbalanced
Input Connectors: Ch's 1-8 ¼" mono TS (tip-sleeve)
..........Receive ¼" mono TS
..........Expand ¼" stereo TRS (tip-ring-sleeve) Tip=Left; Ring=Right
Input Gain Range O to +6 1 dB
RFI Input Filters Yes
Max Output Level: Main +26 (+20) 1 dBu Balanced (Unbalanced)
..........Loop Send +20 1 dBu Unbalanced
..........Expand +20 1 dBu Unbalanced
Output Impedance: Main 100 1% Each Output
..........Loop Send 100 1%
..........Expand 100 1%
Output Design: Main Active Balanced/Unbalanced Dierential line drivers
..........Loop Send Unbalanced
..........Expand Unbalanced
Output Connectors ¼" TRS
Output Gain Range O to +6 2 dB Unbalanced
Frequency Response 20 Hz-20 kHz 3 dB
THD + Noise .015 .005 % +4 dBu, 20-20 kHz
IM Distortion (SMPTE) .01 .005 % 60 Hz/7 kHz, 4:1, +4 dBu
Input Referred Noise -112 1 dBu
Signal-to-Noise Ratio 98 (re +4 dBu, 20 kHz BW) 2 dB All inputs max, 50% out level, balanced
Crosstalk 76 (1 kHz) 2 dB Left-Right
85 (1 kHz) 2 dB Channel to channel
Overload LED resholds +16 1 dBu All critical nodes monitored
Power Supply Requirement 100 to 240 10% VAC 50/60 Hz, 7W
Unit: Conformity CE, FCC, UL
..........Construction
All Steel
..........Size 1.75"H x 19"W x 5.3"D (4.4 cm x 48.3 cm x 13.5 cm)
..........Weight 5 lb (2.3 kg)
Shipping: Size 4.25" x 20.3" x 13.75" (11 cm x 52 cm x 35 cm)
..........Weight 8 lb (3.6 kg)
Note: 0 dBu=0.775 Vrms
