Appendix (English)
Technical Specifications
Input Signal LEDs
Green LED = 50 dBFS
Red LED = 0.5 dBFS
Microphone Inputs
(level set in software)
Input Impedance
2.16 kΩ, Balanced, 1.08 k + 1.08 k
Gain Range (dynamic mic mode)
26–46 dB, in 1 dB steps
Gain Range (condenser mic mode)
14–34 dB, in 1 dB steps
Max. Input (dynamic mic mode)
-16 dBu, Gain = 26 dB
Max. Input (condenser mic mode)
-4 dBu, Gain = 14 dB
Equivalent Input Noise
-121 dBu, 20 kHz BW, Rs = 150 Ω, Gain = 26 dB
CMRR
-70 dB, Rs = 150 Ω, 1 kHz, Gain = 26 dB
Frequency Response
20 Hz – 20 kHz, +0, -0.5 dB, at all Gain settings
THD + Noise
<0.010% @ 1 kHz, 20 kHz BW, Rs = 150 Ω, Output = -6 dBFS, Gain = 26
Phantom Power
24V, 10 mA Max
Digital Codec
48 kHz, 24 bit
1/4” / XLR Balanced Line-
Level Inputs
Input Impedance
10 kΩ Balanced
Gain Range
0–20 dB, in 1 dB steps
Max. Input level (Line Mode)
+24 dBu, 14 Ω, 1 kHz
Frequency Response
20 Hz – 20 kHz, +0, -0.5 dB
Dynamic Range (input)
106 dB (A-weighted)
CMRR
-50 dB, Rs: 50 Ω, 1 kHz
Line+ Mode
+24 dBu, 1 kHz, active, Left ("+") and Right ("–") signals summed to mono
