True to the Music
Radial Engineering Ltd. mPress™ Owner’s Manual
4
pOWeR: 100V to
240V input with secure
XLR connection for
the power supply.
1/4” maIN OUTS: Used
to feed a pair of powered
speakers to supply audio
to the audience.
eXO-pOD gaLLeRY OUTpUTS: Dual
level outputs with high setting to feed
Exo-Pods or line level devices, and low
setting to feed mic level inputs.
pROgRam INpUTS: ¼” and RCA inputs are
for the output of a console or music playback
device. These are wired in parallel with the
front panel program inputs.
XLR maIN OUTpUTS: Used to
feed a pair of powered speak-
ers or mixer to supply audio to
the audience.
gND LIfT: Ground lift
switch disconnects the
ground on pin-1 at the
XLR program outputs.
LOW/HIgH: Recessed
switch sets the output level
for each gallery output.
mIC/LINe INpUTS: When set to MIC,
these are wired in parallel with the front
panel XLR inputs. When set to LINE,
they bypass the mic preamps and di-
rectly feed the main and gallery outputs.
mIC/LINe: Recessed switch
sets both rear XLR inputs to
mic level or line level operation.
ReaR paNeL feaTUReS
