3
True to the Music
Radial Engineering Ltd. mPress™ Owner’s Manual
mIC 1/2: XLR-F inputs used
to connect two microphones
to the mPress.
Hpf: High pass lter
eliminates excessive
resonance and proxim-
ity effect build-up.
LImITeR ON: Used to prevent
loud signals from clipping and
distorting recorder inputs.
pROgRam: Activates the program
inputs with adjustable level control
for the outputs of a mixing console
or music playback device.
TeST: Activates a 1kHz
test tone to test outputs
and set recorder levels.
pHONeS:
¼” TRS
headphone output
with level control.
INpUT: 3.5mm and RCA
consumer line level input
for laptop, tablet or iPod
®
music playback.
LeDs: Metering lets
you know signal is ac-
tive or overloading.
ReLeaSe: Used to set
the speed at which the
limiter resets itself.
maIN OUT LeVeL:
Adjusts the overall
output level going to
the PA system.
maIN OUT ON:
Activates the left
and right MAIN
outputs.
1-2 gaLLeRY OUTpUTS: First two
dual level outputs with high settings to
feed Exo-Pods or line level device, and
a low setting to feed mic level inputs.
48V: Recessed switch acti-
vates 48V phantom power
for condenser mics.
ON: Used to turn on
each MIC input.
gaIN: Control to
set the microphone
input level.
THReSHOLD: Sets
the input voltage level
where the limiter be-
gins to work.
fRONT paNeL feaTUReS
