Radial Engineering Ltd.
Headload Guitar Amp Load Box
True to the Music
®
3
FRONT PANEL FEATURE SET
1. RESONANCE: Increases the high
and low frequency resonance. Used to
compensate for weak bass and/or treble
response when listening at low volume
levels.
2. RANGE: Works with the 20% LOAD
setting to attenuate the speaker power
to 1%.
3. LOAD: Six position rotary switch adjusts
the amount of speaker attenuation. The
OFF setting mutes the speaker for silent
listening or recording.
4. HIGH LOW EQ: Two band equalizer
lets you fi ne tune the Post-EQ JDX
output.
5. PWR LED: Indicator illuminates when
the external power supply is connected.
6. SPEAKER CAB VOICING: Six position
rotary switch offers six speaker voicing
choices.
91 2 3 4 8
765
7. PHAZER ON: This switch is used
to turn the Phazer on/off. An LED
illuminates when Phazer is active.
8. 180°: Sets the range of the SHIFT
control; from 0°-180° with switch out;
from 181°-360° with switch pushed
in. A total of 360° of phase rotation is
available between the two settings.
9. SHIFT: Controls the amount of phase
shift applied to all the JDX outputs.
10. HEADPHONE: Output for ¼” standard
headphones or earbuds. Level control
adjusts the headphone volume.
11. CONSTRUCTION: ‘Road ready’
14-gauge steel enclosure for durability
and improved shielding against stray
magnetic fi elds.
12. HANDLE: Makes transporting the
Headload more convenient. Can be
mounted on the top or side.
10 11
12
