9. Self-learning mode

WARNING!WARNING!

Risk of fatal injury (electric shock) caused by

the motor cable (10) tearing oﬀ.

◆ Ensure that the motor cable (10)

is not taken up and torn oﬀ by moving parts dur-

ing the setting process.

Important conditions for adjusting

the end points and for safe operation

◆ End points must be set in order to switch oﬀ the

motor when they are reached for both directions

of travel, up (▲)/ down (▼).

◆ The tubular motor must be fully installed.

CAUTION!

Risk of injury during the setting process due to

crushing of the hand by moving parts.

◆ Never reach into the area of the winding shaft

(12) or guide rails when the motor is running.

If necessary, you can also set the end points manu-

ally in combination with self-learning mode.

All automatically self-learned end points can be

manually corrected, if necessary.

The RolloTube S-line Zip DuoFern is delivered from

the factory in self-learning mode and can be put

into operation immediately after the electrical con-

nection.

10. Manual adjustment of end points

1. Switch on the mains power supply. When using the

universal setting cable, press the On/Set button.

The RolloTube S-line Zip DuoFern is ready for op-

eration immediately.

▲

▼

First lower and then raise the

screen.

The end positions are automatically

learned during the ﬁrst run cycles.

3. Subsequently check the direction of travel if the

RolloTube S-line Zip DuoFern is being operated

using a switch or button.

Switch the lines for the rotation direction if the di-

rection of travel is wrong, see connection diagram

[ 20 / 21 ] on page 52 / 53 .

Initial installation

During the initial installation, the engineer can adjust

the end points with a universal setting cable (13),

available from a specialist retailer.

More detailed information can be found

in the operating manual of the respec-

tive accessories.

Subsequent modiﬁcation of the end points with

external controllers

If you want to subsequently modify the end points,

you can adjust these with your controller.

The processes must not be interrupted

while learning the lower end point.

While learning the lower end point, it is

important to note that the motor runs

until the screen hangs loosely and then

moves back automatically until the

screen is taut again and stops. This is a

sign that the lower end point has been

learned.

Over-dimensioned tubular motors can

lead to malfunctions during end point

setting in self-learning mode.

Please monitor the screen closely during

this process. If the motor does not stop

when the screen is taut again and raises

the screen again, the motor is over-

dimensioned for the Zip system and the

process must be interrupted. The outer

end point must be set manually in this

case.
