RolloTube S-line Zip DuoFern Small
13
RolloTube S-line Zip DuoFern Medium
2. Saw a groove
1
at the end of the precision tube
so that the cam
of the adapter (4) can be
completely pressed into the tube.
◆ There may not be any play between the groove
1
and the cam
.
◆ The dimensions for the groove
1
are depend-
ent on the respective motor type.
3. Slide the tubular motor into the precision tube.
1. Measure the distance between the adapter (4) and
the rear third of the catch (7) and mark this distance
on the precision tube.
i
Please only use precision tubes
made of aluminium.
ALUMINIUM
7.7 Preparation for the use of precision tubes
