7. Important installation instructions

The preparation measures must be adapted to the

existing Zip system on site, due to the various models

of Zip systems available.

Preparation for the installation

◆ Check that the structural base is suﬃciently stable

for the operation of an electrically powered Zip

system.

◆ Check that the voltage / frequency on the type

plate corresponds to the local mains conditions

prior to installation.

◆ You must remove or deactivate all cables and

equipment not required for operation of the

equipment prior to installation of the tubular

motor.

◆ Moving drive parts to be operated at a height

under 2.5 m from the ﬂoor must be protected.

◆ If the tubular motor is to be controlled with a

switch with a default OFF pre-setting, then the

switch is to be positioned in the line of sight of

the tubular motor away from moving parts and

at a height of at least 1.5 m.

◆ The tubular motor must be easily accessible at a

later stage and the motor cable (10) must be laid

without kinking.

Installing the tubular motor incorrectly can

cause the tubular motor or Zip system to be

damaged.

There is a risk of short circuits and ﬁre in the

event of direct weather inﬂuences to the unpro-

tected tubular motor.

◆ The installed tubular motor may never be sub-

jected to direct rain or snow as this may lead to

life-threatening situations due to short circuiting

and damage to the motor.

◆ Only install the tubular motor in Zip systems where

the motor is structurally protected from direct

rain or snow.

◆ Install a suitable protective hood for the tubular

motor, if necessary.

Drilling and inserting screws in the area of the

drive will cause the tubular motor to be damaged.

Risk of fatal injury from crushing in the event of

operation without set end points.

◆ The end points must be set in order to ensure safe

operation. In order to do so, please refer to the cor-

responding chapter in this manual on page 55.

Risk of injury when working at heights due to

falling.

◆ Take suitable measures to ensure safe working at

heights.

◆ Ensure that ladders or scaﬀolding stand securely.
