Attero Tech by QSC Synapse D32o
User Manual
Ó QSC, LLC 2020 614-00049
*Note: The Synapse D32o has a label on the base of the unit that shows the device’s MAC address. This is important for initial device
identification as the last six digits make up part of the device’s default network name that is shown when the device is detected by Dante™
Controller of unIFY Control Panel.
FRONT PANEL
1 - Headphone Jack
2 - Headphone Mute Indicator
3 - Headphone Volume/Mute Knob
4 - Factory Reset Switch
5 - OLED Display
6 - Front Panel Nav Knob
7 -Monitor Select Switch
8 - Device Power/Status LED
DEVICE FEATURES
REAR PANEL
9 - Bank A (Outputs 1-16)
10 - Bank B Outputs 17-32)
11 - SFP port (Primary)
12 - SFP (Secondary)
13 - Ethernet Port (Primary)
14 - Ethernet Port (Secondary)
15 – DIP Switches (Future Use)
16 - Redundant Power Input
17 - Primary Power Supply
