11
QIO Series Control I/O Expanders - Cont’d
The Q-SYS QIO-LVR4 is a network control endpoint native to the Q-SYS Ecosystem, serving as an IP-to-relay bridge that enables
communication with common motorized motor shades, lighting controllers, as well as other environmental systems via four controllable low-
voltage relays. The compact form factor includes surface mounting hardware permitting discreet and strategic mounting while an optional
rack kit fits one to four devices into a standard 1U nineteen-inch format. Up to four devices may be daisy-chained off one access switch
port, provided 24V DC power is available. Alternatively, each may be individually powered over Ethernet.
Power Requirements
The Q-SYS QIO Series offers a flexible power solution that allows the integrator to choose to use either a 24V DC power supply or Power
over Ethernet (PoE). With either power solution, you must follow the safety instructions for the specific power supply or injector chosen. For
details on the 24V DC or PoE power supply requirements, refer to the product specifications.
WARNING: To avoid the risk of electric shock, this equipment must only be connected to a supply mains with protective earth
when using class I power supply.
Power over Ethernet (PoE)
The QIO-FLEX4A requires an IEEE 802.3at Type 2 (PoE+) PSE or 802.3af Type 1 Class 3 PoE PSE if the device amplifier is not used. All
other QIO models require an 802.3af Type 1 PoE PSE.
NOTE: A device cannot provide daisy-chained power to an external device with Power over Ethernet. An external 24V DC supply
is required for power daisy-chaining applications. A device can provide Ethernet daisy-chaining with either power source.
24V DC External Supply and Daisy-Chained Devices
NOTE: When using an accessory power supply (24V DC @ 3.75A max, less than 100W), a maximum of four (4) quarter-rack
QIO devices, two (2) QIO-FLEX4A devices, or any combination of QIO devices that can fit in a single QIO-RMK Rack Kit may be powered
simultaneously. For rack mounting information, see “Rack Mount Installation” on page 24.
Common
1
Accessory Power Supply Connections: 2-pin Euro connector
White or red wire (24V DC)
Black or bare wire (GND)
or
1 Common accessory power supply wiring provided for reference only. Confirm wire color in the accessory power supply specification.
Specifications and Dimensions
Product specifications and dimension drawings for Q-SYS QIO Endpoints can be found online at qsys.com.
