Handleiding
Je bekijkt pagina 20 van 28
20
•
EN
4
Setup
CAUTION!
Serious injury to persons can be caused if the speaker systems fall down. If you lack the
qualification, do not attempt the installation yourself, but instead use a professional installer. For
commercial use the country-specific accident prevention regulations of the government safety
organization for electrical facilities must be complied with at all times.
Place the speaker systems on a solid surface and align them with the audience. The KX-181A subwoofer
box is stackable and has an M20 flange for mounting the KX-P212A and KX-P215A tops using a distance
tube (accessory). The top units can also be mounted on a stand with a 35 mm tube diameter using their
stand sleeve. Thanks to their slanted housing shape, they can also be used as floor monitors. For additional
mounting options, the housing is provided with two M10 threaded inserts. When positioning the speaker
systems, always ensure that air can flow freely through the cooling fins at the rear to ensure sufficient
cooling.
General notes
• The location must be solid, plane, anti-slip, vibration-
free, oscillation-free, and fire-resistant. The
installation area must hold a minimum point load of
5 times the system's load (e.g. weight 20 kg - point
load 100 kg). The speakers must never be installed
higher than 100 cm without secondary attachment.
• Always install the speaker systems in a way that a
minimum distance of three meters to the audience is
kept. This is the only way to avoid hearing damage for
unreasonable listeners. Block the area in front of the
speaker systems with appropriate means.
• Extreme levels like feedback, bass-hum or the beats
of a dropping microphone can destroy the
loudspeakers within very short time and produce
immediate hearing damage. Such extreme levels
must be avoided at any rate. We recommend using
appropriate equalizers and compressors/limiters.
• For transport, the speaker systems feature two
carrying handles. The speaker system should be
carried without force by two persons of the same size.
Carrying the speaker system as one person alone
should be avoided as the high weight and the strain
could lead to back damages and torsions. Please
note that all speaker systems with more than 25 kg
weight must be transported with two persons.
Stacking
•
It is possible to install 3 subwoofer systems in a
stacked configuration. Always fasten the subwoofers
with appropriate installation straps (not supplied) to
prevent them from flipping over.
Stands/Satellite systems
• Stands must only be installed on a plane area with a
maximum inclination angle of 5°.
• When using stands or satellite systems under the
influence of horizontal forces, e.g. through wind, the
standing safety can be impaired. This is why
additional safety measures like attaching ballast
weights have to be taken.
• If inclined tension cables or prolonged outriggers are
used, the area of danger has to be marked or even be
blocked.
• Before lifting or lowering the telescopic tubes, you
must always block a safety area around the stand or
satellite system. This safety area must have a
diameter of 1.5 times the maximum height.
• Lifted telescopic tubes always have to be secured
with a secondary securing!
• The total weight of the installation (=total weight of all
individual parts) must never exceed the maximum
load of the installation area.
• The stand has to be installed out of the reach of
people.
• An unintended movement of the load has to be
avoided - also in case of fire!
• The installer is responsible for adhering to the
carrying capacity given by the manufacturer, the
safety requirements and the qualification of possible
co-workers.
• When people are located below the load, all
necessary safety measures have to be taken in order
to avoid injury.
• The personnel have to be instructed on the content of
the user manual and on the dangers related with
operating stands.
• Depending upon the individual installation spot, all
necessary measures against movement and for
securing the standing safety have to be created.
• The installation is only allowed on carrying areas. In
some cases, an appropriate substructure, e.g. via a
balancing foot, has to be created. When choosing the
installation material, optimum dimensions have to be
chosen in order to secure maximum safety.
•
Speaker systems installed on stands or satellite
systems may cause severe injuries when crashing! If
installing on slippery surfaces, the legs must be
secured with screws or nails via the provided holes or
an anti-slippery mat has to be used.
