PC-BS3134_IM_12.2024 13.12.24
11
Maintenance
Pull the mains plug out of the socket before cleaning or
maintaining the appliance.
Emptying the Dust Container
Empty the dust collector once the collected dirt reaches the
MAX marking.
1. Disconnect the mains plug from the wall socket.
2. Disconnect the hose from the hose connection.
3. Press the button (14) to release the dust collector.
Remove the dust collector.
4. Empty the dust collector over a dustbin. To do this, pull
the latch on the dust collector to open the base plate.
5. Then close the base plate again.
6. Attach the dust collector to the appliance. First position
it at the bottom of the appliance and then secure it with
the hook on top.
7. Check that the position of the dust collector is secure by
briefly lifting the appliance at its carrying handle.
Filters
Your appliance features 4 filters. The common dust bag
system has been replaced by a transparent dust collector.
The higher flow speed of the collector allows for heavy dirt
and smallest floating particles to be separated from the
“sucked-in air”.
It is thus not necessary to buy dust bags.
The filters must be cleaned regularly.
Filter Insert
CAUTION:
• Never wash the filter in the washing machine.
• Do not use a hairdryer for drying.
• Only use the appliance after the filters have been
installed correctly.
Proceed as follows to remove, clean and reinstall the filter
insert:
1. Empty the dust collector as described previously.
2. Remove the dust collector lid. Turn it anticlockwise in the
direction of
. Pull the lid upwards by the handle.
- The markings
and are embossed above the
hose connection.
3. Remove the fine dust filter. Remove the foam insert from
the fine dust filter.
4. Remove the coarse dirt filter from the dust collector. To
do this, reach into the recesses of the filter and remove it
by pulling it upwards.
5. Use a brush to clean the filters. In case of heavy stain-
ing, clean the filters under running water.
6. Let the filters air-dry completely before refitting them!
7. Wipe the dust collector with a damp cloth and then wipe
it dry.
- If moisture gets into the rubber seal of the base plate,
carefully remove the seal and dry it as well as the
base plate. Replace the seal.
8. Put the coarse dirt filter back into the collector. Make
sure that the guides are seated in the openings.
- The recesses are made in such a way that the
guides fit in one position only. This prevents incorrect
assembly.
9. Insert the foam insert into the fine dust filter. The smooth
side must be visible. Place the fine dust filter onto the
coarse dirt filter.
10. Put the lid back on the dust collector. The guides must
fit into the openings. Press it gently and turn it clockwise
until it clicks into position.
- The recesses are made in such a way that the
guides fit in one position only. This prevents incorrect
assembly.
11. Check that the lid is fitted correctly. Put the dust con-
tainer back into the appliance.
Outlet Filter
The appliance is also equipped with an outlet filter.
It is located on the back of the unit next to the parking aid.
1. Push down the lever and remove the ventilation grille.
2. Remove the filter insert and clean it. You can brush out
the filter.
3. Reinsert the filter. The guide eyes have to point up-
wards.
4. Put the ventilation grille back on the appliance. Observe
the guide lugs. The ventilation grid must engage audibly.
Cleaning
WARNING:
• Pull the mains plug out of the socket before cleaning or main-
taining the appliance.
