PC-BS3134_IM_12.2024 13.12.24
10
Notes for Use
• Dirty filters reduce the suction power of the appliance,
therefore we recommend cleaning the dust container
and the lters after each use.
• The nozzle attachments can be plugged directly onto the
handle connection or onto the mounted suction hose.
• To detach the nozzle attachments, pull them off with a
slight twist.
Floor Nozzle
You can clean smooth surfaces and carpets with the floor
nozzle. It is equipped with rollers to make it easier to guide.
• With the lever (1), you can move the brushes outwards
or inwards.
The optimal use depends on the condition of the floor. We
recommend the following use:
- Use without brushes:
For vacuuming carpeted floors.
- Use with brushes:
For vacuuming smooth floors.
Combined Crevice Nozzle and Brush Nozzle
When folded, you can use this as a crevice nozzle. If you
want to use the brush nozzle, pull the brush part in the
direction of the arrow until it engages mechanically.
- Crevice Nozzle:
Use this to vacuum dirt from corners, joints and small
gaps.
- Brush Nozzle:
Gently removes dirt from slits in upholstery and mat-
tresses. Also suitable for picking up dust on sensitive
surfaces such as furniture or curtains.
Telescopic Suction Pipe
The length of the telescopic suction pipe can be adjusted
individually:
1. Loosen the locking mechanism by sliding
and holding the button in the direction of
the arrow marking.
2. Extract one tube from the other to the
desired length.
3. Release the button in order to lock the
connection.
Mains Cable
Pull the mains cable from the cable compartment. The cable
compartment is located at the back of the appliance below.
CAUTION:
• Pull the mains cable no further than the yellow mark.
• Never pull the power cable up to the red mark as the
cable winder may be damaged. Such damage is not
covered by the warranty.
- If the red mark is visible, pull in the cable with the help of
the cable winding button back to the yellow mark.
Electrical Connection
• Before inserting the mains plug into the socket, check
that the mains voltage is correct. You will find the details
of the appliance on the type plate.
• Only connect the appliance to an approved socket.
Switching the Appliance On / Off
Press the button (16) to switch the appliance on or off.
Start-up
• Insert the connection head of the suction hose into the
hose connection of the appliance. Tighten the connection
header anticlockwise.
• To release the hose again, turn the connecting header
clockwise.
• Insert the vacuum tube into the handle if required.
• Then assemble the floor nozzle and / or the accessories.
To detach the nozzle attachments from the suction pipe,
pull them off by turning them slightly.
Using the Appliance
1. Insert the mains plug into a correctly installed power
socket.
2. Turn the appliance on by the on / off switch by pressing
down the button.
3. Set the “carpet / hard floor” switch, depending on the floor
covering.
4. Vacuum at a steady speed. There is no need to exert
pressure.
- Pay attention to the range that can be covered with
the cable length!
Air Slide
Open the air slide on the hose handle in
order to regulate the airflow or to clear any
particles sticking to the nozzle.
Switching Off and Winding Up the Mains Cable
1. Turn the vacuum cleaner off by the on / off switch and
remove the plug from the socket.
2. Keep the plug in your hand.
3. Press the cable winding button and guide the cable. Hold
the cable to avoid wrapping.
