5
INTRODUCTION
Thank you for choosing a PROEL product. Please take some time to read this manual to understand all the
features of your system and take advantage of all its performance capabilities. All PROEL products are CE
approved and designed for continuous use in professional applications.
DESCRIPTION
V PRO series is the ultimate evolution of the acclaimed V series of PROEL powered loudspeakers. The V PRO
features now a totally new pre-amp section including an advanced processing with high-performance DSP
engine, for a very smooth response and a high-definition sound. The possibility to select the 5 different EQ
presets allows to adapt the system response to the different applications with a touch of your fingers. These
ultra-portable speakers combine, in carefully engineered and light-weight cabinets, the clearest and most
accurate PROEL sound with Class D Amplifier technology and Switch Mode Power Supply, offering an
unbeatable PA solution at its price point. The four models, V8PRO, V10PRO, V12PRO and V15PRO, feature a
new extremely efficient amplifier module capable of delivering 600 W of robust power to the transducers.
Thanks to the use of SMPS technology, this power comes in an ultra-lightweight package, making the V PRO the
most portable PROEL speakers ever.
The V PRO cabinets, expression of the most advanced Italian design, include a super-comfortable luggage-style
top handle for an effortless portability. The slanted shape allows the speakers to be laid on their side and used
also as stage monitors.
Thanks to the MIC/ LINE input and the WIRELESS USB input for the use of PROEL U24 microphone systems, the
V PRO can be used in a variety of applications without external equipment.
MAIN PANEL OPERATIONS
1. INPUT CONNECTOR
This is a COMBO connector that accepts an XLR plug or a JACK plug from any balanced or unbalanced
dynamic microphone or from any line level device or instrument.
The balanced XLR input is wired as follows:
Pin 1 = shield or ground
Pin 2 = + positive or "hot"
Pin 3 = - negative or "cold"
