32
USRMAN_AE604EN_REV003
The SYSTEM INFO sub-menu displays the system information:
Mfg: System manufacturer
Sn: Serial number of the System
Firmware: Software version (visible only at access level 3)
Up-Time: On time (gg – giorni / hh - ore / mm- minuti)
Note: The loaded software / firmware version is visible only at access level 3.
Menù “VOLUMES”
The SYSTEM VOLUMES menù allows you to independently view and configure the volume of each system
sound source / output.
The volumes are displayed as a list and the volume is expressed in decibels referred to 0dB.
The configurable volumes are as follows:
• Main lines 1&2 Amplifier A volume combined with speaker lines 1 and 2.
• Main lines 3&4 Amplifier B volume combined with speaker lines 1 and 2.
• Local fire mic Volume of the emergency microphone integrated on the front.
• Remote fire mic Volume of remote emergency stations connected via bus.
• Ethernet fire mic Volume of remote emergency stations connected via ethernet.
• Msg EVAC Volume of the pre-recorded evacuation message.
• Msg ALARM Volume of the pre-recorded alarm message.
• Local paging Paging input volume integrated in the system.
• Remote paging Volume of paging calls from stations connected via bus.
• Ethernet paging Volume of paging calls from stations connected via ethernet
• Bgm Music 1 Background music volume, integrated input 1.
• Bgm Music 2 Background music volume, integrated input 2.
• Msg Chime Volume of the pre-recorded message of “chime” (Din-Don)
• Msg Gpo 1:8 Generic pre-recorded message volume from 1 to 8.
• Line out Volume uscita di linea integrata.
• Monitor speaker Monitor speaker volume integrated on the front of the system.
To configure a volume simply select the source using the UP and DOWN arrows and press OK, the pointed
volume will be highlighted; using the UP and DOWN arrows, you can change its value, pressing OK saves
and applies the value. When configuring the displayed value is applied in real time, press BACK to go back
to the previous value.
Note: In the absence of line calibration, the Main lines volumes are set to -12dB and cannot be changed.
