18
6 Mix Controls
6.2 Copy Mix
Universal Control for StudioLive
®
Mixers
Software Reference Manual
6.2 Copy Mix
Copying the current mix allows you to quickly set up multiple mixes based on the settings you’ve
already completed.
To copy a mix to any other mix, press the Copy Mix button.
1. Click on the desired destination mix(es).
2. Click Paste to paste the mix or click Cancel to stop the operation.
6.3 Input Channel Controls
6.3.1 Channel Strip
1. Fat Channel Select. Opens the Fat Channel controls for the channel/mix. This
microview displays an overview of the EQ curve you set in the Fat Channel.
See Chapter 7 for more information about the Fat Channel section and
its functions.
2. Solo Button. Turns soloing on and off.
3. Mute Button. Turns muting on and off.
4. Pan Controls. The Pan control sets the channel’s relative position in the left/
right stereo mix. When a pair of channels is stereo linked, the Pan control sets
the spread of the channels in the left/right stereo mix.
5. Compressor Gain Reduction Meter. This meter displays the amount of gain
reduction being applied by the current compressor setting.
Note: This meter is not available for StudioLive AI-series console mixers.
6. Channel Fader. Controls the Overall Level of the Channel. Unity gain (0 dB) is
denoted by a “U.”
7. Gate Gain Reduction Meter. This meter displays the amount of gain reduction
being applied by the current gate setting.
Note: This meter is not available for StudioLive AI-series console mixers.
Level Meter. Displays the prefader level of each channel.
8. Channel Icon. Icons can be added to each channel to provide a quick visual
cue of which instrument is associated with which channel. This is set from the
Channel Settings window. See Section 6.3.3.
9. Channel Name and Color. Each channel can be given a custom name and
custom color for its Select button. This is set from the Channel Settings
window. See Section 6.3.3.
1
2
3
4
5
6
7
8
9
10
