43
7 Fat Channel XT
7.5 Equalizer
PreSonus Plug-Ins
Reference Manual
4 Q. This adjusts the Q value for the corresponding frequency band. The Q is the
ratio of the center frequency to the bandwidth. When the center frequency is
constant, the bandwidth is inversely proportional to the Q, so as you raise the Q,
you narrow the bandwidth. Hence, the smaller the number, the wider the curve.
4 Interactive Graph. This graph provides a visual representation
of the current settings. You can change the settings by moving
the blue dots to adjust the frequency and gain at the same time.
The first time you touch a dot, the associated band automatically
turns on. Tapping or clicking a dot turns the band on and off.
7.5.2 Passive EQ
4 Enable/Disable Click this On/Off switch to enable
or disable the Passive Equalizer module.
4 Low Boost. Sets the level of boost applied around the chosen low frequency.
This control interacts nicely with the Low Attenuation control, allowing for boosts
in apparent bass energy while keeping overall bass energy within optimal limits.
4 Low Attenuation. Sets the level of attenuation applied around
the chosen low frequency. This control interacts nicely with the
Low Boost control, allowing for boosts in apparent bass energy
while keeping overall bass energy within optimal limits.
4 Low Frequency Sets the center frequency of the band covered
by the Low Boost and Low Attenuation controls.
4 High Bandwidth. Sets the bandwidth (Q) for the High Band.
4 High Boost. Boosts the High Band.
4 High Frequency. Sets the center frequency for the High Band.
4 High Attenuation. Sets the attenuation for the High Band.
4 Attenuation Select. Sets the Frequency at which the attenuation begins.
7.5.3 Vintage EQ
4 Enable/Disable. Click the power button to enable
or disable the Vintage Equalizer module.
4 Low Frequency. Sets the corner frequency of the low-frequency
shelving band of this EQ. Choose from 35, 60, 110, or 220 Hz.
