w ww.practixx.com
44
|
GB
NOTE!
Product damage
If the product is operated without or with too little hy-
draulic oil, this can lead to hydraulic pump damage.
NOTE!
Environmental damage!
Spilled oil can pollute the environment permanently.
The liquid is highly toxic and can quickly lead to water
pollution.
- Fill/empty oil only on level, paved surfaces.
- Use a lling nozzle or funnel.
- Collect drained oil in a suitable container.
- Wipe up spilled oil carefully immediately and dis-
pose of the cloth according to local regulations.
- Dispose of oil as per local regulations.
Before each use, always check:
• the connection cables for defective areas (cracks,
cuts and the like),
• The device for possible damage,
• whether all screws are tightened,
• The hydraulic system for leaks,
• The oil level
• The safety devices and
• the ON/OFF switch.
Environmental conditions
The product must work under the following environ-
mental conditions:
Minimum Maximum Recommended
Temperature
5 °C 40°C 16°C
Humidity 95% 70%
When working below 5°C, the device should be idled
for approx. 15 minutes to allow the hydraulic oil to warm
up.
• The mains power connection is protected with a 16A
slow-blow fuse.
• The “RCD circuit breaker” must have a 30mA trip
rating.
Required accessories:
• Grease or spray oil
Not included in the scope of delivery.
9.8 Fitting the trunk lifter (7) (Fig. 10)
Note: The chain of the trunk lifter may only be
attached to the chain hook using the last link for
safety reasons.
1. Mount the log lifter (7) with a hexagon bolt
M12x70mm (7a), washer and lock nut to the hold-
er of the base plate (11), the lock nut must be on
the right side (towards the wheels)! Use two 19mm
open-ended spanners / socket spanners.
2. Slide the log lift support (10) into the recess. Fix
the log lift support (10) with a hexagon socket
screw M6x10mm (10a).
3. Attach the chain (28) to the trunk lifter (7) in the fol-
lowing order: Hexagonal bolt M12x40mm (28a),
washer,trunk lifter bracket (7b), washer, chain
(28), washer and locking nut. Screw on the lock
nut only so far that the chain (28) can move freely.
Attention! The chain (28) must turn completely smooth-
ly on the hexagon head screw M12x40mm (28a)!
4. Hang the end of the chain in the chain hook (22).
9.9 Fitting the trunk lifter lock (26) (Fig. 11)
1. Mount the lever (27) with a hexagon bolt M8x55mm
(26a), washer and lock nut to the trunk lift lock (26).
Use two 13mm open-ended spanners / socket
spanners.
2. Slide the trunk lift latch (26) into the holder.
3. Insert the hexagonal bolts M8x55mm (26b) with a
washer through each of the holes.
4. Secure the hexagonal bolts M8x55mm (26b) with
one washer and one locknut each. Use two 13mm
open-ended spanners / socket spanners.
5. Check the ease of the lever (27).
10. Before commissioning
m Attention!
Always make sure the product is fully assembled
before commissioning!
m Attention!
Before performing setting or maintenance work,
unplug the mains plug!
m WARNING!
Health hazard!
Inhalation of oil vapours and exhaust gases can cause
serious damage to health, unconsciousness and in ex-
treme cases death.
- Do not breathe in oil vapours and exhaust gases.
- Operate the device outdoors only.
