w ww.practixx.com
GB
|
23
Switching ON / OFF (g. 4)
Switching ON: Press the operating switch (3).
Switching OFF: Release the operating switch (3).
Continuous operation: Press operating switch (3)
and lock with locking switch (4).
Stop continuous operation: Press and release oper-
ating switch (3).
10. Electrical connection
The electrical motor installed is connected and
ready for operation. The connection complies with
the applicable VDE and DIN provisions.
The customer‘s mains connection as well as the
extension cable used must also comply with these
regulations.
Damaged electrical connection cable
The insulation on electrical connection cables is often
damaged.
This may have the following causes:
• Pressure points, where connection cables are
passed through windows or doors
• Kinks where the connection cable has been improp-
erly fastened or routed
• Places where the connection cables have been cut
due to being driven over
• Insulation damage due to being ripped out of the wall
outlet.
• Cracks due to the insulation ageing.
Such damaged electrical connection cables must not
be used and are life-threatening due to the insulation
damage.
Check the electrical connection cables for damage
regularly. Ensure that the connection cables are dis-
connected from electrical power when checking for
damage.
Electrical connection cables must comply with the ap-
plicable VDE and DIN provisions. Only use connection
cables with the designation H07RN-F
The printing of the type designation on the connection
cable is mandatory.
Connection type Y
If the mains connection cable of this device is dam-
aged, it must be replaced by the manufacturer, their
service department or a similarly qualied person to
avoid dangers.
Inserting the tool (Fig. 2)
• Clean tool before use and lightly grease tool shaft
with drill grease.
• Pull back the locking sleeve (7) and hold in place.
• Push the dust-free tool into the tool receiver up to
the stop while rotating it. The tool will lock itself in
place.
• Check the locking mechanism by pulling on the tool.
Removing the tool
• Pull back the locking sleeve (7) and hold it in place
and remove the tool.
Always keep chisel tools sharp.
Attention:
• Only work with low pressure when chiselling.
• Too much pressure puts unnecessary strain on the
motor.
• Sharpen chisels in good time and replace if neces-
sary.
Dust/chip extraction
Dusts from materials such as paint containing lead,
some types of wood, minerals and metal can be harm-
ful to health. Touching or inhaling the dust can cause
allergic
reactions and/or respiratory diseases of the user or
other people in the vicinity.
Certain dusts such as oak or beech dust are consid-
ered carcinogenic, especially in combination with
additives for wood treatment (chromate, wood preserv-
atives). Material containing asbestos may only be pro-
cessed by specialists.
• Make sure that the work area is well-ventilated.
• It is recommended to wear respirators with lter
class P2.
Observe the regulations for the materials to be pro-
cessed applicable in your country.
9. Operation
ATTENTION!
Always make sure the device is fully assembled
before commissioning!
Danger!
To avoid a hazard, the machine may only be held by
the two handles (2/5)!
