2. Product iNtroductioN

PowerWalker User Manual

2.1 Product Overview

Intended Use

The PowerWalker Solar Inverter SAN series are transformerless hybrid inverters with IP65 protection level for

both indoor and outdoor use. They are equipped with 2 MPP trackers and a battery connection that can

1) increase the PV energy yield where the roof has varying orientations or is subject to shading;

2) increase the self-consumption of solar energy by directly charging the high-voltage energy storage

battery, in particular lithium iron phosphate (LiFePO4) batteries compatible with the SAN series or lead-

acid batteries from the direct current (DC) generated by the PV array for later use when the sun is not

available;

3) convert the direct current (DC) to alternating current (AC) for use at homes, commercial buildings or for

charging EVs;

4) feed in the excess PV power into the grid to earn extra income;

5) discharge the unused battery power and feed it into the grid;

6) charge the battery also from the grid in the case when the PV power is insufficient;

7) provide backup power from the battery to the preset load in case of power outage;

8) monitor and configure settings via Bluetooth or Wi-Fi connection from smartphones, tablets or PCs. The

app allows users to prioritise the distribution of PV power and set the priority of the power source when

PV power is insufficient.

Compatible lithium iron phosphate (LiFePO4) batteries

Battery Type: High Voltage

Manufacturer Battery Model

PowerWalker LiFe Battery System 102-37/HV1

Pylontech Force-H1

Dyness Tower T

T7/T10/T14/T17/T21

WECO WECO 5K3-XP

EMEA

Monitoring

Device

Cloud

Inverter

Back-up Load

Energy Meter

Grid

Application of Hybrid Solar Inverter with Energy Storage

Battery

Normal Load

2 1

1 4 7 10

3 6 9 10
