OBM-4K-IP Series
4K-IP LCD Professional Monitor
12G-SDI / SFP-IP
22
User Configuraon Menu
Page 2/7
- The following funcons are assigned in the factory.
[F1 Buon] : Color Temp
[F2 Buon] : Audio Level Meter
[F3 Buon] : Time Code
[F4 Buon] : Zebra & False Color
[F5 Buon] : Focus Assist
Input Seng
SDI Signal Format
- Selects the format of 3G / 6G / 12G SDI input
signal.
[Auto],[A 4:4:4 YUV 10b],[A 4:4:4 GBR 10b],
[A 4:4:4 YUV 12b],[A 4:4:4 GBR 12b],
[A 4:2:2 YUV 12b],[B DL 4:4:4 YUV 10/12b],
[B DL 4:4:4 GBR 10/12b],[B DL 4:2:2 YUV 12b],
[B DL 4:2:2 YUV 10b 60p]
12G Image Division
- Selects the image division of the 12G-SDI
Single Link signal between [2-Sample Interleave]
and [Square]
**Payload ID of 12G-SDI 2-Sample Interleave
signal and 12G-SDI Square division signal is the
same. So, Image Division cannot be detected
automacally, and the user has to select it.
The default seng is [2-Sample Interleave].
Image Division & Link Order
- Select from [Manual] or [Auto].
[Auto]:
Square / 2-S.I. The input automacally recognizes
the VPID (Video Payload ID) embedded in the SDI
signal when it is normally present, and even if the
input is not connected properly, it splits the
image or links in order to reduce user error.
Set automacally.
Also, when 12 signals are input, it automacally
switches to single mode.
* When Dual 6G/3G 2-S.I. signal is input in Single
mode, it switches to Dual Link 2-S.I. mode.
Audio delay seng
Audio delay (lip sync)
-Set the delay me between the video and
audio signals. (0ms to 170ms). 17 steps.
