Part 20
the printer will keep on beeping at Paper End (completely no paper) till paper is
replaced when S2-5 is “ON”. When S2-5 is “OFF”, the printer will keep on
beeping every 3 seconds at Paper Near End (still long paper in replace) till paper is
replaced.
For switch position 2-6 and when it is set to ON, the printer responds to a carriage
return command (CR code or 0Dh) with also a line feed (LF code or 0Ah) action.
Then if the text editor always expresses the change to a new line with both the CR
and LF codes, there will be an extra line advance than expected. However it works
for some old editors that express the change to a new line with only either one of
the LF code or the CR code.
Switch position 2-7 defines the parity check regulation in serial interface.
In PP-8800, it is selectable between even and none.
For switch position 2- 8 can choice the handshaking method in serial interface.
When it is set to ON, the printer transmits an “XOFF” for busy and sends an
“XON” for not busy. When it is set to OFF, the printer signifies the busy status
over hardware signals that can be detected by the host as “DSR” or “CTS”.
SW3 Switch Poison Behavior Table
Switch
position
ON
OFF
1
Raster Bitmap Print by line print.
Raster Bitmap Print by buffer batch.
2~4
Reserved.
5~8
Print Density Adjust
For switch position 3-1, it defines the printing behavior of the printer on graphic
printing. When it is set to ON, the printer prints on each printing command
received immediately. However, the printer may have to engage brake frequently
waiting for next command resulting in trembling. When this switch is set to OFF,
the printer starts printing only when more graphical data are collected thus
performing a much smoother printing operation.
Effect of positions 5, 6 , 7 & 8 on Print Density is defined as below:
SW3 Pos.5
OFF
ON
OFF
ON
OFF
ON
OFF
ON
OFF
ON
OFF
ON
OFF
SW3 Pos.6
OFF
OFF
ON
ON
OFF
OFF
ON
ON
OFF
OFF
ON
ON
OFF
SW3 Pos.7
OFF
OFF
OFF
OFF
ON
ON
ON
ON
OFF
OFF
OFF
OFF
ON
SW3 Pos.8
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
ON
ON
ON
ON
ON
Print
Density (%)
100
105
110
115
120
125
130
95
90
85
80
75
70
Since the qualities of different paper are not alike, please regulate the print density
and printing speed to obtain the satisfaction of printing quality.
SW4 Switch Poison Behavior Table
Switch
position
ON
OFF
1
Available “Beep” sounds after printing.
Disable “Beep” sounds after printing.
2~3
Barcode Height Reduction. (Refer to the table below)
4~5
Line Space Reduction (Refer to the table below)
