Je bekijkt pagina 33 van 45
33
● LS200-TC: IP65 LoRaWAN Machine Temperature Sensor
When LS200-TC is compared with the last reported values, the temperature
change is expected to exceed 10 °C (by default). It will report values at the
Min. Time interval. If it does not exceed 10 °C (by default), it will report values
at the Max. Time interval.
● LS200-LG: IP65 LoRaWAN Refrigerator Temperature and Humidity Sensor
Compare the illumination value detected by the illumination sensor with the set
illumination value. The detected value exceeds the set value (default 50 lux),
the currently detected illumination value is sent.
● LS200-CM3/LS200-CM: IP53 LoRaWAN Current Meter
The 3-phase current meter (LS200-CM3) samples the current according to Min.
Time. If the current value sampled this time relatively exceeds the set value
(the default is 100 mA) more than the current value reported last time,
the device will immediately report the current value sampled this time. If the
current variation does not exceed the default value, the data will be reported
regularly according to Max. Time.
1. When using it, the back of it can be adsorbed on the iron surface, or the two
endscanbexedtothewallwithscrews.
2. When installing theLS200-CM3 current transformer, please separate the live
and neutral wires of the wire to be detected, and only take the live wire
through current transformer and start the measurement according to the
wiring below:
If the live wire and the neutral wire are connected together at the same time,
theywilloseteachotherandthemeasurementis0.
“L
K” is marked on the bottom of the CT.
