23
LS250-PLUG
Product LS250-PLUG
Wireless Transmission
Technology LoRaWAN
Frequency
EU868: 863 to 870 MHz
US915: 902 to 928 MHz
TX Power
US915: 20 dBm EU868: 16 dBm
AS923: 16 dBm (optional) KR920: 14 dBm (optional)
AU915: 20 dBm(optional) IN865: 20 dBm (optional)
Rx Sensitivity
-136 dBm (LoRa, Spreading Factor = 12, Bitrate = 293 bps)
-121 dBm (FSK, Frequency Deviation = 5 kHz, Bitrate = 1.2 kbps)
Work Mode OTAA/ABP Class C
Data Interfaces
Power Supply 100 V AC to 240 V AC, 50/60Hz
Physical Characteristics
Dimensions (L x W x H) 95 mm x 58 mm x 42.5 mm
Weight 135 g
Sensor Measurement
Info
Current
- Measurement Range: 100 mA to 16 A
Resistive load:16A/250VAC;P:4000VA
Inductive load (max.):8A/220VAC;P:1760VA(COSφ=0.4)
Rated Load:
- EU type: 16 A/250 V AC
- UK type: 13 A/250 V AC
- AU type: 10 A/250 V AC
- US type: 15 A/125 V AC
Electric motor (max.): 1.5 HP/240 V AC
Ingress Protection IP20
Operating Temperature -20 °C to 55 °C
Relative Humidity < 90 % RH (non-condensing)
Storage Temperature -40 °C to 85 °C
Standards Conformance
Regulatory Compliance CE RED, FCC PART 15B
