IGT-2205AT-E
4
Product Specications
Model
IGT-2205AT-E
Hardware Specications
Copper Port
2 x 10/100/1000BASE-T RJ45 TP
Auto-MDI/MDI-X, auto-negotiation
SFP / mini-GBIC Slots
2 x 100/1000BASE-X SFP interfaces
Supports auto detection
DIP Switch
DIP Function ON OFF
1 Fiber Redundancy
Port 3 and Port 4 are both linked;
only Port 3 transmits data. If Port 3
fails, trafc will switch to Port 4.
Port 3 and Port 4 are both linked and
can transmit data simultaneously.
2 Flow Control
Pauses transmission when receiver
is busy to reduce packet loss
No ow control; data sends
continuously, may lose packets
3 Broadcast Storm Restraint
Limits broadcast trafc to prevent
network overload.
No limit; broadcasts may cause
network congestion.
4
Fiber Port Speed
Selection
Can link and transmit data at both
100/1000 Mbps.
Can only link and transmit data at
1000 Mbps.
Connector
Removable 4-pin terminal block
Pin 1/2 for Power 1; Pin 3/4 for Power 2
LED
System and Power:
■ Green: Power 1
■ Red: Alarm
Per Copper Port (Port-1~ Port-2):
■ Green: Port LNK/ACT
■ Amber:1G LNK
SFP interface (Port-3~ Port-4)
■ Green: 1G LNK/ACT
ESD Protection 4KV DC
Enclosure IP40 type metal case
Installation DIN-rail kit (Side wall mount is an optional accessory)
Dimensions (W x D x H) 26 x 85 x 85mm
Weight 294g
Power Requirements
DC 12~58V
Redundant power with reverse polarity protection
Power Consumption / Dissipation
Max. 0.58 watts/1.98 BTU (Power on without any connection)
Max. 3.5 watts/11.94 BTU (Ethernet full loading)
Switch Specication
Switch Processing Scheme Store-and-Forward
Address Table 8K entries
Maximum Transmit Unit 10K bytes
Switch fabric 8Gbps
Throughput (packet per second) 11.9Mpps@64bytes
Flow Control
Back pressure for half duplex
IEEE 802.3x pause frame for full duplex
Standards Conformance
Standards Compliance
IEEE 802.3 Ethernet
IEEE 802.3u Fast Ethernet
IEEE 802.3ab Gigabit Ethernet
IEEE 802.3z Gigabit Ethernet 1000BASE-SX/LX
IEEE 802.3x Full-Duplex Flow Control
IEEE 802.3az Energy Efcient Ethernet
Regulatory Compliance FCC Part 15 Class A, CE
Stability Testing
IEC60068-2-32 (Free fall)
IEC60068-2-27 (Shock)
IEC60068-2-6 (Vibration)
Environment
Temperature
Operating: -40~75 degrees C
Storage: -40~75 degrees C
Humidity
Operating: 5~95% (non-condensing)
Storage: 5~95% (non-condensing)
