Handleiding

IGT-2205AT-E

Hardened Environment Application

PLANET IGT-2205AT-E Industrial Gigabit Media Converter offers full-port Gigabit transmission speed. It is designed with high reliability and security to

ensure continuous operation in harsh environments such as transportation control cabinets, factory floors, outdoor installations, and locations with extreme

temperatures. In addition, the IGT-2205AT-E is compatible with 100/1000Mbps SFP transceivers to provide a stable, long-distance connection and flexible

industrial networking deployment.

Applications

Redundancy Application

The IGT-2205AT-E Industrial Gigabit Media Converter supports rapid fiber link redundancy for mission-critical Ethernet applications. The redundant mode

features an auto-recovery function—when the destination port of a packet is link-down, the converter will automatically forward the packet to the backup port,

ensuring uninterrupted communication.

Maintenance Shop

Control Center

Subway 1

Subway 2

I/O

20km

50km

Outdoor

IP Camera

Outdoor

IP Camera

Serial over

Ethernet Device

PLC

Robot

I/O I/O

1000

100BASE-FX Fiber Optic

100

1000BASE-SX/LX Fiber Optic

1000

100BASE-TX UTP

I/O

DI/DO

Fiber Switch

120km

IGT-2205AT-E

100

Link Path Redundancy for Critical Network Service

Gigabit

Ethernet Switch

Data Server

1000BASE-T UTP

1000BASE-SX/LX Fiber Optic

1000

Server

(ATM/IP Camera/

Security Machine)

Gigabit

Ethernet Switch

1000

Redundant Link

1000BASE-X Fiber

(Disabled)

Primary Link

1000BASE-X Fiber

(Forwarding)

IGT-2205AT-E

Fiber Redundant Mode
