User’s Manual of IGS-5225 series
76
2.3.1 Installing the SFP Transceiver
The sections describe how to insert an SFP/SFP+ transceiver into an SFP/SFP+ slot. The SFP/SFP+ transceivers are hot-
pluggable and hot-swappable. You can plug in and out the transceiver to/from any SFP/SFP+ port without having to power
down the Industrial Managed Switch as Figure 2-19 appears.
Figure 2-23: Plugging in the SFP/SFP+ Transceiver
Approved PLANET SFP Transceivers
PLANET Industrial Managed PoE+ Switch supports both single mode and multi-mode SFP transceivers. The following
list of approved PLANET SFP transceivers is correct at the time of publication:
Fast Ethernet Transceiver (100BASE-X SFP)
Model
Speed (Mbps)
Connector
Interface
Fiber Mode
Distance
Wavelength (nm)
Operating Temp.
MFB-FX
100
LC
Multi-Mode
2km
1310nm
0 ~ 60℃
MFB-F20
100
LC
Single Mode
20km
1310nm
0 ~ 60℃
MFB-F40
100
LC
Single Mode
40km
1310nm
0 ~ 60℃
MFB-F60
100
LC
Single Mode
60km
1310nm
0 ~ 60℃
MFB-F120
100
LC
Single Mode
120km
1550nm
0 ~ 60℃
MFB-TFX
100
LC
Multi-Mode
2km
1310nm
-40 ~ 85℃
MFB-TF20
100
LC
Single Mode
20km
1310nm
-40 ~ 85℃
MFB-TF120
100
LC
Single Mode
120km
1550nm
-40 ~ 85℃
