User’s Manual of IGS-5225 series
75
2.3 Cabling
10/100/1000BASE-T
All 10/100/1000BASE-T ports come with auto-negotiation capability. They automatically support 1000BASE-T, 100BASE-
TX and 10BASE-T networks. Users only need to plug a working network device into one of the 10/100/1000BASE-T ports,
and then turn on the Industrial Managed Switch. The port will automatically run at 10Mbps, 20Mbps, 100Mbps or
200Mbps and 1000Mbps or 2000Mbps after negotiating with the connected device.
100BASE-FX/1000BASE/2500BASE-X
The Industrial Managed Switch has two/four SFP interfaces that support 100/1000/2500Mbps triple speed mode (optional
multi-mode/single-mode 100BASE-FX/1000BASE/2500BASE-X SFP module)
Cabling
Each 10/100/1000BASE-T port uses an RJ45 socket -- similar to phone jacks -- for connection of unshielded twisted-pair
cable (UTP). The IEEE 802.3/802.3u 802.3ab Fast/Gigabit Ethernet standard requires Category 5 UTP for 100Mbps
100BASE-TX. 10BASE-T networks can use Cat.3, 4, 5 or 1000BASE-T use 5/5e/6 UTP (see table below). Maximum
distance is 100 meters (328 feet). The 100BASE-FX/1000BASE-X/2500BASE-X SFP slot uses an LC connector with
optional SFP module. Please see table below and know more about the cable specifications.
Port Type
Cable Type
Connector
10BASE-T
Cat3, 4, 5, 2-pair
RJ45
100BASE-TX
Cat5 UTP, 2-pair
RJ45
1000BASE-T
Cat5/5e/6 UTP, 2-pair
RJ45
100BASE-FX
50/125µm or 62.5/125µm multi-mode 9/125µm single-mode
LC (multi/single mode)
1000BASE-SX/LX
50/125µm or 62.5/125µm multi-mode 9/125µm single-mode
LC (multi/single mode)
2.5GBASE-SX/LX
50/125µm or 62.5 / 125µm multi-mode 9/125µm single-mode
LC (multi/single mode)
Any Ethernet devices like hubs and PCs can connect to the Industrial Managed Switch by using straight-through wires.
The two 10/100/1000Mbps ports are auto-MDI/MDI-X and can be used on straight-through or crossover cable.
