User’s Manual of IGS-5225 series
59
Per 10/100/1000BASE-T Port with PoE (Port-1~Port-8)
LED
Color
Function
10/100/1000
LNK/ACT
Green
Lights
Indicating the port is running at 1000Mbps speed and successfully established.
Blinks
Indicating that the switch is actively sending or receiving data over that port.
PoE-in-Use
Amber
Lights
Indicating the port is providing 12~54V DC in-line power.
Off
Indicating the connected device is not a PoE PD.
Per 100/1000BASE-X SFP Interface (Port-9~Port-10)
LED
Color
Function
1000
LNK/ACT
Green
Lights
Indicating the port is running at 1000Mbps speed and successfully established.
Blinks
Indicating that the switch is actively sending or receiving data over that port.
100
LNK/ACT
Amber
Lights
Indicating the port is running at 100Mbps speed and successfully established.
Blinks
Indicating that the switch is actively sending or receiving data over that port.
Per 100/1000/2500BASE-X SFP Interface (Port-11~Port-12)
LED
Color
Function
1000/2500
LNK/ACT
Green
Lights
Indicating the port is running at 1000Mbps or 2500Mbps speed and successfully
established.
Blinks
Indicating that the switch is actively sending or receiving data over that port.
100
LNK/ACT
Amber
Lights
Indicating the port is running at 100Mbps speed and successfully established.
Blinks
Indicating that the switch is actively sending or receiving data over that port.
■ PoE Power Usage (Unit: Watt)
LED
Color
Function
60
Amber
Lights:
To indicate the system consumes over 60-watt PoE power budget
120
Amber
Lights:
To indicate the system consumes over 120-watt PoE power budget
180
Amber
Lights:
To indicate the system consumes over 180-watt PoE power budget
240
Amber
Lights:
To indicate the system consumes over 240-watt PoE power budget
