User’s Manual of IGS-5225 series
55
10/100/1000T RJ45 Ports (Port 5)
LED
Color
Function
1000
LNK/ACT
Green
Lights:
To indicate the port is successfully established.
Blinks:
To indicate that the switch is actively sending or receiving data over that port.
10/100
LNK/ACT
Amber
Lights:
To indicate the port is successfully established.
Blinks:
To indicate that the switch is actively sending or receiving data over that port.
SFP Interfaces (Port 6 to port 7)
LED
Color
Function
1G/2.5G
LNK/ACT
Green
Lights:
To indicate the link through that port is successfully established at
1G/2.5Gbps.
Blinks:
To indicate that the switch is actively sending or receiving data over that port.
100
LNK/ACT
Amber
Lights:
To indicate the link through that port is successfully established at 100Mbps.
Blinks:
To indicate that the switch is actively sending or receiving data over that port.
PoE Power Usage (Unit: Watt)
LED
Color
Function
90W
Amber
Lights: To indicate the system consumes over 90-watt PoE power budget.
Slow Blinks: To indicate the system is providing 45-watt~90-watt PoE power usage.
180W
Amber
Lights: To indicate the system consumes over 180-watt PoE power budget.
Slow Blinks: To indicate the system is providing 135-watt~180-watt PoE power usage.
270W
Amber
Lights: To indicate the system consumes over 270-watt PoE power budget.
Slow Blinks: To indicate the system is providing 225-watt~270-watt PoE power usage.
360W
Amber
Slow Blinks: To indicate the system is providing 315-watt~360-watt PoE power usage.
