User’s Manual of IGS-5225 series
343
4.4.4.3 DSCP Translation
This page allows you to configure the basic QoS DSCP Translation settings for all switches. DSCP translation can be done in
Ingress or Egress. The DSCP Translation screen in Figure 4-4-4-3 appears.
Figure 4-4-4-3: DSCP Translation Page Screenshot
The page includes the following fields:
Object
Description
DSCP
Maximum number of supported DSCP values are 64 and valid DSCP value
ranges from 0 to 63.
Ingress
Ingress side DSCP can be first translated to new DSCP before using the DSCP
for QoS class and DPL map.
There are two configuration parameters for DSCP Translation –
■ Translate
■ Classify
Translate
DSCP at Ingress side can be translated to any of (0-63) DSCP values.
Classify
Click to enable Classification at Ingress side.
Egress
There is following configurable parameter for Egress side -
■ Remap
Remap DP
Select the DSCP value from select menu to which you want to remap. DSCP
value ranges form 0 to 63.
Buttons
: Click to apply changes
: Click to undo any changes made locally and revert to previously saved values.
