User’s Manual of IGS-5225 series
342
always taken from the 'DSCP Translation->Egress Remap DP0' table.
Remap DP Aware: DSCP from analyzer is remapped and frame is
remarked with remapped DSCP value. Depending on the DP level of the
frame, the remapped DSCP value is either taken from the 'DSCP
Translation->Egress Remap DP0' table or from the 'DSCP Translation-
>Egress Remap DP1' table.
Buttons
: Click to apply changes
: Click to undo any changes made locally and revert to previously saved values.
4.4.4.2 DSCP-based QoS
This page allows you to configure the basic QoS DSCP-based QoS Ingress Classification settings for all switches. The DSCP-
based QoS screen in Figure 4-4-4-2 appears.
Figure 4-4-4-2: DSCP-based QoS Ingress Classification Page Screenshot
The page includes the following fields:
Object
Description
DSCP
Maximum number of supported DSCP values are 64.
Trust
Controls whether a specific DSCP value is trusted. Only frames with trusted
DSCP values are mapped to a specific QoS class and Drop Precedence Level.
Frames with untrusted DSCP values are treated as a non-IP frame.
QoS Class
QoS Class value can be any of (0-7)
DPL
Drop Precedence Level (0-1)
