User’s Manual of IGS-5225 series
309
If Format is Two Octets, the following applies: Name[0] and Name[1] will both
be interpreted as unsigned 8-bit integers (allowing a range of [0;
255]). Name[0] will be placed in the PDU before Name[1].
The remaining available bytes in name will not be used.
If Format is Y1731 ICC, the following applies:
length must be 13.
Contents must be in range [a-z,A-Z,0-9]
Y.1731 specifies that it is a concatenation of ICC (ITU Carrier Code) and UMC
(Unique MEG ID Code):
ICC: 1-6 bytes
UMC: 7-12 bytes
In principle UMC can be any value in range [1; 127], but this API does not allow
for specifying length of ICC, so the underlying code doesn't know where ICC
ends and UMC starts.
The Domain Format must be None.
If Format is Y1731 ICC CC, the following applies:
length must be 15.
First 2 chars (CC): Must be amongst [A-Z]
Next 1-6 chars (ICC): Must be amongst [a-z,A-Z,0-9]
Next 7-12 chars (UMC): Must be amongst [a-z,A-Z,0-9]
There may be ONE (slash) present in name[3-7].
The Domain format must be None.
VLAN
The MA's primary VID. A primary VID of 0 means that all MEPs created within
this MA will be created as port MEPs (interface MEPs). There can only be one
port MEP per interface. A given port MEP may still be created with tags, if that
MEP's VLAN is non-zero."
A non-zero primary VID means that all MEPs created within this MA will be
created as VLAN MEPs. A given MEP may be configured with another VLAN
than the MA's primary VID, but it is impossible to have untagged VLAN MEPs.
CCM Interval
The CCM rate of all MEPs bound to this Service.
TLV Option Select
Sender Id: Default Sender ID TLV format to be used in CCMs generated by this
Service.
None Do not include Sender ID TLVs.
Chassis Enable Sender ID TLV and send Chassis ID (MAC Address).
Manage Enable Sender ID TLV and send Management address (IPv4 Address).
ChassisManage Enable Sender ID TLV and send both Chassis ID (MAC
Address) and Management Address (IPv4 Address).
