User’s Manual of IGS-5225 series
308
4.3.18.3 Service
Configure CFM Service parameters on this page.
Figure 4-3-18-3: CFM Service Configuration
Configure CFM Service parameters on this page.
Object
Description
Delete
Check to delete the entry. It will be deleted during the next save.
Domain
Name of Domain under which this Service resides.
Service
Name of Service. Value is a single word which begins with an alphabetic letter
A-Z or a-z with length 1-15.
Format
Select the short Service name format. This decides how the value of the Name
parameter will be interpreted. To mimic Y.1731 MEG IDs, create an MD instance
with an empty name and use Y1731 ICC or Y1731 ICC CC.
Possible values are:
String
Two Octets
Y1731 ICC
Y1731 ICC CC
Look under Name for explanation.
Name
The contents of this parameter depends on the value of the format member.
Besides the limitations explained for each of them, the following applies in
general:
If the Domain Format is None, the size of this cannot exceed 45 bytes.
If the Domain Format is not None, the size of this cannot exceed 44 bytes.
If Format is String, the following applies:
length must be in range [1; 44]
Contents must be in range [32; 126]
