User’s Manual of IGS-5225 series
299
The page includes the following fields:
General Settings
Object
Description
Port
The switch port number.
Event Name
Name of the Link Event which is being configured.
Error Window
Represents the window period in the order of 1 sec for the observation of
various link events.
Error Threshold
Represents the threshold value for the window period for the appropriate Link
event so as to notify the peer of this error.
Error Frame Event
The Errored Frame Event counts the number of errored frames detected during
the specified period. The period is specified by a time interval ( Window in order
of 1 sec). This event is generated if the errored frame count is equal to or
greater than the specified threshold for that period (Period Threshold). Errored
frames are frames that had transmission errors as detected at the Media Access
Control sublayer. Error Window for 'Error Frame Event' must be an integer value
between 1-60 and its default value is '1'. Whereas Error Threshold must be
between 0-4294967295 and its default value is '1'.
Symbol Period Error
Event
ved in a time interval on the underlying physical layer. This event is generated if
the symbol error count is equal to or greater than the specified threshold for that
period. Error Window for 'Symbol Period Error Event' must be an integer value
between 1-60 and its default value is '1'. Whereas Error Threshold must be
between 0-4294967295 and its default value is '1'.
Seconds Summary
Event
The Errored Frame Seconds Summary Event TLV counts the number of errored
frame seconds that occurred during the specified period. The period is specified
by a time interval. This event is generated if the number of errored frame
seconds is equal to or greater than the specified threshold for that period. An
errored frame second is a one second interval wherein at least one frame error
was detected. Errored frames are frames that had transmission errors as
detected at the Media Access Control sublayer. Error Window for 'Seconds
Summary Event' must be an integer value between 10-900 and its default value
is '60'. Whereas Error Threshold must be between 0-65535 and its default value
is '1'.
Buttons
Click to save changes.
: Click to undo any changes made locally and revert to previously saved values.
