User’s Manual of IGS-5225 series
298
transmitted Event Notification OAMPDU Sequence Number.
Rx and Tx Loopback
Control
A count of the number of Loopback Control OAMPDUs received and transmitted
on this interface.
Rx and Tx Variable
Request
A count of the number of Variable Request OAMPDUs received and transmitted
on this interface.
Rx and Tx Variable
Response
A count of the number of Variable Response OAMPDUs received and
transmitted on this interface.
Rx and Tx Org Specific
PDU's
A count of the number of Organization Specific OAMPDUs transmitted on this
interface.
Rx and Tx
Unsupported Codes
A count of the number of OAMPDUs transmitted on this interface with an
unsupported op-code.
Rx and Tx Link fault
PDU's
A count of the number of Link fault PDU's received and transmitted on this
interface.
Rx and Tx Dying Gasp
A count of the number of Dying Gasp events received and transmitted on this
interface.
Rx and Tx Critical
Event PDU's
A count of the number of Critical event PDU's received and transmitted on this
interface.
Buttons
: Click to refresh the page immediately.
: Clears the counters for the selected port.
4.3.17.4 Event Settings
This page allows the user to inspect the current Link OAM Link Event configurations, and change them as well, as screen in
Figure 4-3-17-4 appears.
Figure 4-3-17-4: Event Settings Page Screenshot
