User’s Manual of IGS-5225 series
27
Weight
1103g
1100g
1104g
1128g
Installation
DIN-rail kit and wall-mount kit
Power Requirements
Dual 48~56V DC (>52V DC for PoE+ output recommended)
Dual 12~54V DC
Power
Consumption
Without
PoE
Max. 6.48
watts/22.11BTU
Max. 12.2
watts/41.63BTU
Max. 6.48
watts/22.11BTU
Max. 7.28
watts/22.11BTU
Full
Loading
PoE
Max. 271 watts/
924.65BTU
Max. 258.5 watts/
882.04BTU
Max.262
watts/893.42BTU
Max.249
watts/849.09BTU
ESD Protection
Air 8KV DC
Contact 6KV DC
Surge Protection
4KV DC
LED Indicator
System:
Power 1 (Green), Power 2 (Green)
Alarm (Red)
Ring (Green), Ring Owner (Green)
DIDO (Red)
Per 10/100/1000T RJ45 PoE+ Ports:
PoE-in-Use (Amber)
LNK/ACT (Green)
Per SFP Interface:
100 LNK/ACT (Amber)
1000/2500 LNK/ACT (Green)
PoE Usage:
60W, 120W, 180W, 240W (Amber)
Switching Specifications
Switch Architecture
Store-and-Forward
Switch Fabric
30Gbps/non-blocking
24Gbps/non-blocking
30Gbps/non-blocking
30Gbps/non-blocking
Throughput (packet per
second)
22.32Mpps@ 64
bytes packet
17.85Mpps@ 64
bytes packet
22.32Mpps@ 64
bytes packet
22.32Mpps@ 64 bytes
packet
Address Table
8K entries, automatic source address learning and aging
Shared Data Buffer
4Mbits
Flow Control
IEEE 802.3x pause frame for full duplex
Back pressure for half duplex
Jumbo Frame
9Kbytes
Power over Ethernet
PoE Standard
IEEE 802.3at Power over Ethernet Plus/PSE
PoE Power Supply Type
End-span
PoE Power Output
IEEE 802.3af Standard
