User’s Manual of IGS-5225 series
26
1.5 Product Specifications
IGS-5225-8P2T2S / IGS-5225-8P2T4S / IGS-5225-8P4S / IGS-5225-8P4S-12V
Product
IGS-5225-8P2T2S
IGS-5225-8P2T4S
IGS-5225-8P4S
IGS-5225-8P4S-12V
Hardware Specifications
Copper Ports
10
10/100/1000BASE-T
RJ45 auto-MDI/MDI-X
ports
10
10/100/1000BASE-T
RJ45 auto-MDI/MDI-X
ports
8
10/100/1000BASE-T
RJ45
auto-MDI/MDI-X ports
8
10/100/1000BASE-T
RJ45
auto-MDI/MDI-X ports
SFP Ports
2
2500BASE-X SFP
interfaces
(Port-11to Port-12)
Compatible with
100BASE-FX and
1000B ASE-X SFP
2
1000BASE-SX/LX/BX
SFP interfaces
(Port-11 to Port-12)
Compatible with
100BASE-FX SFP
2
1000BASE-SX/LX/BX
SFP interfaces
(Port-11 to Port-12)
Compatible with
100BASE-FX SFP
2
1000BASE-SX/LX/BX
SFP interfaces
(Port-11 to Port-12)
Compatible with
100BASE-FX SFP
2
2500BASE-X SFP
interfaces
(Port-13 to Port-14)
Compatible with
100BASE-FX and
1000B ASE-X SFP
2
2500BASE-X SFP
interfaces
(Port-13 to Port-14)
Compatible with
100BASE-FX and
1000B ASE-X SFP
2
2500BASE-X SFP
interfaces
(Port-13 to Port-14)
Compatible with
100BASE-FX and
1000B ASE-X SFP
PoE Injector Port
8 ports with 802.3at/af PoE injector function (Ports 1 to 8)
Console
1 x RJ45-to-RS232 serial port (115200, 8, N, 1)
Reset Button
< 5 sec: System reboot
> 5 sec: Factory default
Connector
Removable 6-pin terminal block for power input
Pin 1/2 for Power 1, Pin 3/4 for fault alarm, Pin 5/6 for Power 2
Removable 6-pin terminal block for DI/DO interface
Pin 1/2 for DI 1 & 2, Pin 3/4 for DO 1 & 2, Pin 5/6 for GND
Alarm
One relay output for power failure. Alarm relay current carry ability: 1A @ 24V DC
Digital Input (DI)
2 digital input:
Level 0: -24~2.1V (±0.1V)
Level 1: 2.1~24V (±0.1V)
Input load to 24V DC, 10mA max.
Digital Output (DO)
2 digital output:
Open collector to 24VDC, 100mA
Enclosure
IP30 aluminum case
Dimensions (WxDxH)
76 x 107 x 152 mm
