User’s Manual of IGS-5225 series
253
4.3.10.8 IGMP Group Information
Entries in the IGMP Group Table are shown on this Page. The IGMP Group Table is sorted first by VLAN ID, and then by
group.
Each page shows up to 99 entries from the IGMP Group table, default being 20, selected through the "entries per page" input
field. When first visited, the web page will show the first 20 entries from the beginning of the IGMP Group Table. The "Start
from VLAN", and "group" input fields allow the user to select the starting point in the IGMP Group Table. The IGMP Groups
Information screen in Figure 4-3-10-11 appears.
Figure 4-3-10-11: IGMP Snooping Groups Information Page Screenshot
The page includes the following fields:
Object
Description
VLAN ID
VLAN ID of the group.
Groups
Group address of the group displayed.
Port Members
Ports under this group.
Buttons
Auto-refresh : Automatic refresh occurs every 3 seconds.
: Refreshes the displayed table starting from the input fields.
: Updates the table, starting with the first entry in the IGMP Group Table.
: Updates the table, starting with the entry after the last entry currently displayed.
