User’s Manual of GS-6322 Managed Switch Series
38
■ AC Power Receptacle
For compatibility with electrical voltages in most areas of the world, the Managed Switch’s modular power supply can
automatically adjust line power in the range of 100-240V AC and 50/60 Hz. However, if your’d like to have maximum
power output, it’s required specific power input.
Plug the female C15 end of the power cord firmly into the receptacle on the rear panel of the Managed Switch and the
other end of the power cord into an electrical outlet and the power will be ready.
Power Notice:
The device is a power-required device, which means it will not work till it is powered. If your networks
should be active all the time, please consider using UPS (Uninterrupted Power Supply) for your device.
It will prevent you from network data loss or network downtime. In some areas, installing a surge
suppression device may also help to protect your Managed Switch from being damaged by
unregulated surge or current to the Switch or the power adapter.
■ Power Eject button
The GS-6322-Series is equipped a power eject button for sate operations and indications of power supplies. When system
runs is EPS mode, activate the power eject button for ensuring system normal operation. The system detects current PoE
usage and controls the PoE output under minimum PoE budget that the power supply can offer.
LED
Color
Function
Eject
Red
Blinks:
To indicate that the switch is processing PoE budget and PoE ports.
links: To indicate that the power supply was removed accidentally.
Green
Lights: To indicate that it’s safe to remove power supply.
links: To indicate that the switch is working on safe protection for removing
power supply.
Blinks:
To indicate that the process of safe protection is activated or done.
