User’s Manual of GS-6322 Managed Switch Series
37
2.1.3 Switch Rear Panel
The rear panel of the Managed Switch consists of the two CRPS power module slots. Figures 2-1-3 and Figure 2-1-4 show the
rear panels of the Managed Switches.
GS-6322-24P4X Rear Panel
Figure 2-1-5: Rear Panel of GS-6322-24P4X
Figure 2-1-6: Rear Panel of GS-6322-24P4X with two power modules
GS-6322-48UP4X Rear Panel
Figure 2-1-7: Rear Panel of GS-6322-48UP4X
Figure 2-1-8: Rear Panel of GS-6322-48UP4Xv with two power modules
■ Power Requirements
The GS-6322-Series is designed with two modular power supply slots. It can work with three optional 920W/1200W/2000W AC
power supplies. The final package of switch and power supplies will depend on your purchase. It doesn’t install a powers upply
by default. Please contact your local distributor or retailer for confirming your purchase package.
