73
33. Turn the middle door hinge (H) through 180
0
. Align the middle door hinge
(H) to the prepared holes on the left side properly (s. fig. below). While doing
so, insert the hinge axis of the middle door hinge into the upper hinge hole of
the freezer door. Screw the hinge using the self-tapping screws (I); s. fig. below.
34. Meanwhile, hold the freezer door with your hand so it cannot drop down.
35. Ensure that the freezer door is fixed safely and properly by the hinges.
NOTICE! Adjust the door properly before you finally tighten the screws of
the hinge. The seal must close properly.
H
MIDDLE DOOR HINGE
I
SELF-TAPPING SCREW OF THE MIDDLE DOOR HINGE
36. Attach the fridge door to the middle door hinge. For this purpose, insert the
hinge axis of the middle door hinge into the bottom hinge hole of the fridge
door carefully. Hold the door in position (s. fig. below).
