3
i2600
English
Rear Panel
13. Channel Inputs
These two XLR input connections are for balanced line-level
connections to be sent into the i2600.
14. Channel A Mic/Line Switch
This switch allows the user to adjust the input sensitivity of the
Channel A input between microphone and line, thus allowing
microphones to also be used for this connection. The microphone
setting can only be used for the i2600’s RTA function that allows
the unit to analyze the room and create settings based on this
data.
15. Channel Outputs
These XLR connectors are for connecting the i2600 to external
input devices such as ampliers or powered speakers.
16. AES/EBU Input
This XLR input is for the connection of digital AES/EBU signals.
The i2600 is capable of accepting digital signals with sampling
rates of 44.1kHz or 48kHz.
17. AC Power Input
Connect the included AC power cable to this connector. The other
end should be connected to an appropriate power source. The i2600
universal switching power operates between 90VAC ~ 240 VAC.
18. Power Switch
This switch turns the i2600 on and off.
1 2 3
4 5 6 7 8
10
11
18 17 16 15 14
13
9
12
