TP 6…PS
22/30
PHOENIX CONTACT 4109_en_E
Current and power data
Power consumption, maximum @ 24 V
TP 6070-WVPS
TP 6101-WXPS
TP 6121-WXPS
TP 6156-WHPS
TP 6185-WHPS
TP 6215-WHPS
14.71 W
19.01 W
21.53 W
30.48 W
32.16 W
32.88 W
Operating systems
Operating system (configuration option) Windows
®
Embedded Compact 7
Data storage
Type eMMC 8 GB
Main memory
RAM 1 GB
Processor data
Processor ARM Cortex-A9
Clock speed 800 MHz
Number of cores 4
Interfaces
Data port 2x Type A USB 2.0
MicroSD
Serial connection 1x D-SUB 9 (male), configurable via Visu+ (Express) for
RS-232/422/485
*
Number of Ethernet connectors 1
Ethernet connection 10/100/1000 Mbps
*
This is a limited implementation of the EIA-232 standard.
Display (TP 6070-WVPS)
Display size, inch (cm) 7 (17.8)
Type TFT
Resolution, W x H (pixels) 800 x 480
Number of colors 16.7 million
Touch technology PCAP (10 point)
Brightness (cd/m²) 500
Backlight LED
Backlight MTBF (hours) 50000
Viewing angle (horizontal/vertical) 89°
Panel cutout size, W x H (mm) 195 x 139
