Technical appendix
4109_en_E PHOENIX CONTACT 21/30
A Technical appendix
General data
Overall, dimensions (width x height x depth)
*
TP 6070-WVPS
TP 6101-WXPS
TP 6121-WXPS
TP 6156-WHPS
TP 6185-WHPS
TP 6215-WHPS
202 x 146 x 51 mm
263 x 200 x 51 mm
302 x 229 x 51 mm
398 x 273 x 51 mm
465 x 310 x 51 mm
532 x 346 x 51 mm
Ambient temperature (operation)
TP 6070-WVPS, TP 6101-WXPS, TP 6121-WXPS
TP 6156-WHPS, TP 6185-WHPS, TP 6215-WHPS
-20 … 50°C
0 … 50°C
Ambient temperature (storage/transport)
TP 6070-WVPS, TP 6101-WXPS, TP 6121-WXPS
TP 6156-WHPS, TP 6185-WHPS, TP 6215-WHPS
-25 … 85°C
-20 … 60°C
Permissible humidity (relative)
TP 6070-WVPS, TP 6101-WXPS, TP 6121-WXPS
TP 6156-WHPS, TP 6185-WHPS, TP 6215-WHPS
5% … 85%, non-condensing
10% … 95%, non-condensing
Weight
TP 6070-WVPS
TP 6101-WXPS
TP 6121-WXPS
TP 6156-WHPS
TP 6185-WHPS
TP 6215-WHPS
1.3 kg
2.1 kg
2.5 kg
4.3 kg
5.2 kg
6.3 kg
Degree of protection IP66 front, IP20 rear
Mounting Panel cutout
LED indicators Power, bicolor
*
Dimensions are overall, including bezel
Electrical data
Power supply, nominal 24 V DC ±20%
Type of connection Removable screw-type and screw lug
Conductor size 0.2 … 2.5 mm² (24 … 12 AWG)
Torque, wire clamping screw 0.5 … 0.6 Nm
RTC battery, typical life 5 years
Fuse Integrated
Protection against polarity reversal Diode
