Installation

105608_en_01 PHOENIX CONTACT 49

6.5 Installing the SCK-C-MODBUS communication

module

6.5.1 Addressing the SCK-C-MODBUS communication module

The device may only be opened to set the required address or baud rate.

The communication module may only be addressed when disconnected from the power

supply and from the RS-485 and SCK bus lines.

Inside the communication module, the Modbus address and the baud rate are binary coded

with eight DIP switches each. To set these properties, proceed as follows:

1. Carefully open the housing cover using a suitable screwdriver.

2. Carefully pull the PCB out.

3. Locate the DIP switches (top: Modbus address, bottom: baud rate).

T6

T5

T7

T8

G

N

D

2

G

N

D

2

B

A

C

O

M

+

2

4

V

G

N

D

1

G

N

D

1

+24v+24V GND1 G

T6

T5

T7

T8

G

N

D

2

G

N

D

2

B

A

COM

+24v+24V GND1 G

+24V

GND1

+

2

4

V

ON

1234 567 8

ON

1234 567 8
